Chapter 56: Shipbuilding | Wall-climbing robots perform hull rust removal and painting in shipyards, eliminating scaffolding and rope access hazards. | 56.1 Chapter Summary | This chapter examines the use of wall-climbing robots in shipbuilding and ship repair, with particular attention to hull surface preparation and coating. Ship hulls are among the most demanding surfaces a robot can encounter. They are enormous, curved in multiple directions, exposed to salt water and marine organisms, and subject to strict regulatory oversight. Traditionally, the work of removing rust, old paint, and marine growth from a hull has been done by human workers standing on scaffolding, hanging from ropes, or operating inside dry docks and floating docks. Each of these methods carries serious safety risks and significant cost. Wall-climbing robots offer an alternative. They can adhere to a vertical or inclined steel surface, carry tools for grit blasting or water jetting, and apply anti-corrosion and anti-fouling coatings with consistent quality. This chapter explains how these robots work, what they are used for, and how the shipbuilding industry has adopted them. It also compares shipbuilding with other industries that use similar climbing robots, so that the reader can see both the common technical threads and the unique demands of the shipyard environment. |
| 56.2 Why Ship Hulls Are a Special Case | A ship hull is not simply a large steel wall. It is a complex, three-dimensional structure with flat panels, compound curves, welded seams, and a variety of appendages such as rudders, stabilizers, sea chests, and propeller shafts. The hull below the waterline is constantly attacked by seawater, which causes corrosion, and by marine organisms such as barnacles, mussels, and algae, which attach themselves to the surface and increase drag. A fouled hull can increase fuel consumption by a substantial margin, which is why ship owners and operators invest heavily in hull cleaning and coating. | The traditional approach to hull maintenance has several drawbacks. Scaffolding must be erected around the hull, which is time-consuming and expensive. Rope access, in which workers hang from the deck or from temporary anchor points, is dangerous and physically exhausting. Dry docking, in which the ship is lifted out of the water, is costly and may require the ship to be taken out of service for an extended period. Floating docks and slipways have similar limitations. In addition, the materials used in hull preparation and coating, such as abrasive grit, antifouling paint, and solvents, can be hazardous to human health. Workers who perform these tasks are exposed to dust, fumes, noise, and the risk of falls from height. For all these reasons, shipyards have a strong incentive to automate hull surface work. |
| 56.3 How Wall-Climbing Robots Work | A wall-climbing robot for ship hull work must solve three basic problems: adhesion, locomotion, and tooling. Adhesion is the ability to stay attached to a vertical or overhead surface. Locomotion is the ability to move across that surface in a controlled way. Tooling is the ability to perform a useful task, such as blasting, cleaning, or painting, while attached. | Adhesion methods fall into several categories. Magnetic adhesion uses permanent magnets or electromagnets to hold the robot to a ferrous surface. Because most ship hulls are made of steel, magnetic adhesion is a natural choice. Permanent magnets are simple and require no power, but they can be difficult to release. Electromagnets can be switched on and off, which makes them easier to control, but they require a continuous supply of electrical power. A common compromise is to use a combination of permanent magnets and electromagnets, or to use magnetic wheels that roll along the surface while maintaining contact. Vacuum adhesion uses suction cups or a sealed chamber with a fan or pump to create a pressure difference between the inside and outside of the robot. Vacuum adhesion works on non-ferrous surfaces such as aluminum or composite materials, but it requires a good seal and a smooth surface. For ship hulls, which are often rough and covered with rust or marine growth, vacuum adhesion can be less reliable than magnetic adhesion. Thrust adhesion uses propellers or fans to push the robot against the surface. This method is common in aerial drones that inspect bridges and buildings, but it is less common in ship hull work because it requires a large amount of power and can be affected by wind. Climbing mechanisms based on legs or tracks can also be used, but they are more complex and often slower than wheeled or tracked robots. | Locomotion methods include wheels, tracks, and legs. Wheeled robots are simple, fast, and energy-efficient, but they can lose traction on curved or irregular surfaces. Tracked robots have a larger contact area and can handle rougher terrain, but they are heavier and less maneuverable. Legged robots can step over obstacles and adapt to complex geometry, but they are mechanically complex and require sophisticated control. For ship hull work, the most common configuration is a wheeled or tracked robot with magnetic adhesion, sometimes assisted by vacuum or suction cups for additional safety. | Tooling is the part of the robot that does the actual work. For rust removal, common tools include abrasive blasting nozzles, high-pressure water jets, and rotary wire brushes. For painting, common tools include spray guns, rollers, and electrostatic coating heads. The robot must be able to carry the tool, position it accurately, and manage the supply of grit, water, paint, or compressed air. In many cases, the tool is connected to the robot by a hose or cable that also provides power and control signals. This umbilical cord can limit the robot's range and maneuverability, so some advanced systems use onboard batteries and wireless communication. |
| 56.4 The Shipbuilding and Ship Repair Workflow | To understand where wall-climbing robots fit, it is helpful to review the typical workflow of shipbuilding and ship repair. A new ship is built in a shipyard from steel plates and sections. The hull is assembled, welded, and then prepared for coating. The preparation stage includes surface cleaning, rust removal, and application of primer and anti-corrosion coatings. The ship is then launched and outfitted with engines, electrical systems, and other equipment. After delivery, the ship enters service and requires periodic maintenance. Maintenance includes inspection, cleaning, repair, and recoating. The most intensive maintenance is usually performed during dry docking, when the ship is lifted out of the water so that the entire hull can be accessed. | Wall-climbing robots can be used in several stages of this workflow. In new construction, they can be used to prepare and coat large flat areas of the hull, especially in the block assembly stage before the sections are joined. In repair and maintenance, they can be used to clean and recoat the hull while the ship is in dry dock or afloat. They can also be used for inspection, such as measuring coating thickness or detecting cracks and corrosion. In some cases, they can be used for underwater cleaning, although underwater operation introduces additional challenges such as visibility, buoyancy, and corrosion of the robot itself. |
| 56.5 Rust Removal with Wall-Climbing Robots | Rust removal is one of the most important and most difficult tasks in ship hull maintenance. Rust is iron oxide that forms when steel is exposed to water and oxygen. It weakens the steel and must be removed before new coating can be applied. Traditional rust removal methods include manual chipping, wire brushing, sandblasting, and high-pressure water jetting. These methods are labor-intensive, generate large amounts of dust and waste, and expose workers to health hazards. | A wall-climbing robot for rust removal typically carries a blasting nozzle or a water jetting head. The robot moves across the hull surface in a planned pattern, removing rust and old coating as it goes. The abrasive grit or water is supplied through a hose from a support unit on the dock or on the deck. The robot may have a shroud or enclosure around the tool to contain the dust and debris, which is then collected by a vacuum system. This containment is important for two reasons: it protects the environment and the workers, and it allows the abrasive or water to be recycled or disposed of properly. | Several shipyards around the world have adopted robotic blasting systems. In South Korea, for example, major shipbuilders have developed crawler-type robots that use magnetic wheels to climb the hull and blast the surface with steel grit. These robots can cover large areas quickly and can operate in conditions that would be unsafe for humans. In Europe, similar systems have been developed for both shipyards and offshore platforms. In the United States, the Navy and private shipyards have experimented with robotic systems for hull cleaning and painting, often as part of broader programs to reduce worker exposure to hazardous materials. | One of the key advantages of robotic rust removal is consistency. A human worker with a blasting nozzle may miss spots, apply uneven pressure, or become fatigued over the course of a shift. A robot can maintain a constant distance and speed, which produces a more uniform surface profile. This uniformity is important because coatings adhere better to a properly prepared surface. A robot can also record data about the surface, such as its profile and cleanliness, which can be used for quality control. |
| 56.6 Painting and Coating with Wall-Climbing Robots | After rust removal, the hull must be coated to protect it from corrosion and marine growth. Coating systems typically consist of multiple layers: a primer, an intermediate coat, and a topcoat. The primer provides adhesion and corrosion resistance. The intermediate coat builds thickness and provides a barrier. The topcoat provides resistance to seawater, sunlight, and mechanical damage. Anti-fouling coatings are often applied as a final layer to prevent marine organisms from attaching to the hull. | Applying these coatings to a large ship hull is a major undertaking. A single coat may cover tens of thousands of square meters. The coating must be applied at the correct thickness, with the correct overlap between passes, and under the correct environmental conditions of temperature and humidity. Human painters use spray guns or rollers, often while standing on scaffolding or hanging from ropes. This work is physically demanding and exposes workers to solvents and other chemicals. | Wall-climbing robots for painting typically carry a spray gun or a roller. The robot moves across the hull in a programmed pattern, applying the coating in overlapping passes. The paint is supplied through a hose from a pump unit. The robot may have sensors to measure the thickness of the coating and to adjust the flow rate accordingly. Some systems use electrostatic spraying, in which the paint particles are electrically charged and attracted to the grounded hull, which reduces overspray and improves transfer efficiency. | Robotic painting has several advantages. It reduces worker exposure to hazardous chemicals. It improves consistency and reduces waste. It can operate in conditions that are uncomfortable or dangerous for humans, such as in strong winds or in confined spaces. It can also be integrated with inspection systems, so that the coating thickness is measured and recorded automatically. | Several companies have developed wall-climbing robots specifically for hull painting. In Norway, for example, a robot called a hull cleaning and painting robot has been used on offshore vessels and ferries. In Japan, shipyards have developed robots that can apply anti-fouling paint to large areas of a hull. In China, research institutions and shipyards have collaborated on robotic systems for both new construction and repair. |
| 56.7 Inspection and Maintenance with Wall-Climbing Robots | In addition to rust removal and painting, wall-climbing robots can perform inspection and maintenance tasks. Inspection is important because it allows ship owners to detect problems before they become serious. A robot can carry cameras, ultrasonic sensors, or eddy current probes to inspect the hull for cracks, corrosion, and coating defects. It can also measure the thickness of the steel and the coating. This data can be stored and compared over time to track the condition of the hull. | Maintenance tasks include cleaning, such as removing marine growth or salt deposits, and repair, such as welding or patching small areas of damage. Some robots are equipped with tools for these tasks, while others are designed to prepare the surface for human workers who follow behind. In some cases, the robot can perform the task entirely on its own, which reduces the need for human workers to enter dangerous or confined spaces. | One interesting application is the use of wall-climbing robots for underwater inspection. Underwater hull inspection is traditionally performed by divers, who face risks such as decompression sickness, entanglement, and low visibility. A remotely operated vehicle (ROV) or an autonomous underwater vehicle (AUV) can perform some of these tasks, but these vehicles are not always able to maintain contact with the hull. A wall-climbing robot that can adhere to the hull underwater can provide a more stable platform for sensors and tools. Underwater adhesion is challenging because of buoyancy, currents, and the presence of marine growth, but several research groups and companies have developed prototypes and commercial systems. |
| 56.8 Examples from the Shipbuilding Industry | To make the discussion concrete, it is useful to look at specific examples from the shipbuilding industry. These examples show how wall-climbing robots have been used in practice and what benefits they have delivered. | The first example comes from South Korea, which has one of the largest shipbuilding industries in the world. Korean shipyards such as Hyundai Heavy Industries, Samsung Heavy Industries, and Daewoo Shipbuilding and Marine Engineering have developed and deployed robotic systems for hull surface preparation and coating. One system uses a crawler robot with magnetic wheels that can climb the vertical hull of a ship under construction. The robot carries a blasting nozzle and a vacuum recovery system. It can remove rust and old coating from the hull and collect the debris, which reduces dust and pollution. The robot is controlled by an operator on the ground, who uses a joystick and a video feed to guide it. The system has been used on oil tankers, container ships, and liquefied natural gas carriers. The shipyards report that the robot reduces the time required for surface preparation and improves the quality of the surface, which leads to better coating adhesion. | The second example comes from Europe, where shipyards and research institutions have collaborated on robotic systems for hull maintenance. In the Netherlands, a project called Robotic Hull Cleaning developed a robot that can clean and inspect the hull of a ship while it is in dry dock. The robot uses a combination of magnetic adhesion and vacuum suction to stay attached to the hull. It carries a high-pressure water jet for cleaning and a camera for inspection. The system is designed to be modular, so that different tools can be attached depending on the task. The project demonstrated that the robot could clean a hull faster and more consistently than human workers, and that it could operate in areas that were difficult to reach with scaffolding. | The third example comes from the United States, where the Navy has invested in robotic systems for ship maintenance. The Navy operates a large fleet of ships that require regular maintenance and repair. In one program, the Navy developed a wall-climbing robot for inspecting and cleaning the hulls of ships in dry dock. The robot uses magnetic wheels and a modular tool head. It can carry a camera, a coating thickness gauge, or a cleaning tool. The Navy has used the robot to inspect the hulls of aircraft carriers, destroyers, and submarines. The robot reduces the need for sailors and civilian workers to work at height, which improves safety and reduces cost. | The fourth example comes from Japan, where shipyards have developed robots for applying anti-fouling coatings. Anti-fouling coatings are important because they prevent marine organisms from attaching to the hull, which reduces drag and fuel consumption. However, these coatings often contain biocides that are hazardous to human health. By using a robot to apply the coating, shipyards can reduce worker exposure and improve the consistency of the application. One Japanese system uses a robot with a spray gun that moves along the hull on a rail system. The robot is programmed to apply the coating in a precise pattern, which ensures that the coating is uniform and that the correct amount is used. | The fifth example comes from China, where shipyards and universities have collaborated on robotic systems for hull cleaning and painting. One system uses a robot with magnetic tracks that can climb the hull of a ship and perform blasting, cleaning, and painting. The robot is equipped with sensors that measure the thickness of the coating and the roughness of the surface. The data is used to adjust the robot's speed and the flow rate of the coating. The system has been tested on bulk carriers and container ships. The developers report that the robot reduces the time required for hull maintenance and improves the quality of the coating. | The sixth example comes from the offshore industry, which shares many of the same challenges as shipbuilding. Offshore platforms and wind turbines have large steel structures that must be inspected, cleaned, and painted. Wall-climbing robots have been developed for these tasks as well. One system uses a robot with magnetic wheels that can climb the legs of an offshore platform. The robot carries a camera and a cleaning tool. It can inspect the structure for corrosion and remove marine growth. Another system uses a robot with a robotic arm that can perform welding and repair tasks. These examples show that the technology developed for shipbuilding can be adapted to other industries. |
| 56.9 Comparison with Other Industries | Wall-climbing robots are not unique to shipbuilding. Similar robots are used in construction, power generation, oil and gas, and infrastructure inspection. By comparing these applications, we can see which technical solutions are common and which are specific to shipbuilding. | In construction, wall-climbing robots are used for tasks such as concrete inspection, facade cleaning, and painting. These robots often use vacuum adhesion because concrete and glass are not ferromagnetic. They may use legs or tracks to move across rough surfaces. The main challenge in construction is the variety of surfaces and the presence of obstacles such as windows, pipes, and balconies. Ship hulls are more uniform in material but more complex in geometry, especially around the bow and stern. | In power generation, wall-climbing robots are used to inspect and maintain boilers, tanks, and pipes. These environments are often confined and hazardous, with high temperatures and radiation. Robots used in these environments must be robust and reliable, and they must be able to operate in areas that are difficult for humans to reach. The adhesion method may be magnetic, vacuum, or a combination. The tools may include cameras, ultrasonic sensors, and cleaning devices. Shipbuilding shares the need for robustness and reliability, but the scale of the hull is much larger. | In oil and gas, wall-climbing robots are used to inspect and maintain offshore platforms, pipelines, and storage tanks. These robots must be able to operate in explosive atmospheres, which requires special design to prevent sparks and overheating. They must also be able to withstand salt water and harsh weather. Shipbuilding shares these requirements, especially for ships that operate in harsh environments. | In infrastructure inspection, wall-climbing robots are used to inspect bridges, dams, and buildings. These robots often use vacuum adhesion or thrust adhesion, and they may be equipped with cameras, laser scanners, and ground-penetrating radar. The main challenge is the size and complexity of the structures, which may require the robot to travel long distances and to operate in difficult conditions. Shipbuilding shares the need for long travel and difficult conditions, but the hull is a moving structure when the ship is afloat, which adds an additional challenge. | One important difference between shipbuilding and other industries is the regulatory environment. Ships are subject to international regulations, such as those of the International Maritime Organization, which govern the design, construction, and maintenance of ships. These regulations include requirements for coating systems, inspection intervals, and worker safety. Robots used in shipbuilding must comply with these regulations, which may require additional testing and certification. In other industries, the regulations may be different or less stringent. | Another difference is the economic scale. A large ship may have a hull area of tens of thousands of square meters. The cost of preparing and coating this area is enormous. Even a small improvement in efficiency or quality can result in significant savings. This economic incentive has driven shipyards to invest in robotic systems. In other industries, the scale may be smaller, and the economic incentive may be less strong. |
| 56.10 Technical Challenges and Solutions | Wall-climbing robots for ship hull work face several technical challenges. Understanding these challenges and the solutions that have been developed is important for anyone who wants to apply this technology. | The first challenge is adhesion on curved and irregular surfaces. A ship hull is not flat. It curves in multiple directions, and it may have welds, rivets, and other irregularities. A robot that uses magnetic wheels may lose contact with the surface when it encounters a curve or an obstacle. To solve this problem, designers use flexible magnetic wheels or tracks that can conform to the surface. They may also use multiple magnetic units that can move independently, so that the robot maintains contact even when the surface is uneven. In some cases, the robot uses a combination of magnetic adhesion and vacuum suction, so that if one method fails, the other can still hold the robot in place. | The second challenge is navigation and positioning. The robot must know where it is on the hull and where it is going. This is difficult because the hull is a large, featureless surface, and GPS is not available inside a dry dock or on the side of a ship. To solve this problem, designers use a combination of sensors, such as encoders on the wheels, inertial measurement units, and cameras. They may also use external reference points, such as markers placed on the hull or a laser tracker on the dock. The robot's control system uses this information to plan a path and to adjust the robot's position as it moves. | The third challenge is tooling and process control. The robot must be able to perform the task, whether it is blasting, cleaning, or painting, with the correct parameters. For blasting, the robot must maintain the correct distance and angle between the nozzle and the surface. For painting, the robot must maintain the correct distance, angle, and speed, and it must control the flow rate of the paint. To solve this problem, designers use sensors to measure the process and feedback control to adjust the robot's motion. For example, a robot that is painting may use a laser sensor to measure the thickness of the coating and adjust the speed of the robot or the flow rate of the paint. | The fourth challenge is power and communication. The robot needs power to move and to operate its tools. It also needs communication to receive commands and to send data. In many cases, the robot is connected to a support unit by a cable or hose that provides power, compressed air, and paint or grit. This umbilical cord can limit the robot's range and maneuverability, and it can be a safety hazard if it becomes entangled. To solve this problem, some designers use onboard batteries and wireless communication. However, batteries add weight and require recharging, and wireless communication can be unreliable in a shipyard environment. The choice between tethered and untethered operation depends on the task and the environment. | The fifth challenge is safety. A wall-climbing robot that falls from a ship hull can injure people and damage equipment. To solve this problem, designers use redundant adhesion systems, safety ropes, and fall arrest systems. They also use sensors to detect when the robot is losing adhesion and to stop the robot before it falls. In addition, the robot must be designed to operate safely in the presence of humans, who may be working nearby. This requires careful planning and training. | The sixth challenge is cost. Wall-climbing robots are expensive to develop and to purchase. They require maintenance and spare parts. They may require specialized operators. For some shipyards, the cost may be difficult to justify, especially if the yard is small or if the work is not repetitive. To solve this problem, designers are working to reduce the cost of components and to develop modular systems that can be adapted to different tasks. They are also working to demonstrate the economic benefits of robotic systems, such as reduced labor costs, improved quality, and reduced downtime. |
| 56.11 Economic and Safety Benefits | The adoption of wall-climbing robots in shipbuilding has both economic and safety benefits. These benefits are the main reason why shipyards and ship owners invest in the technology. | The economic benefits include reduced labor costs, reduced downtime, and improved quality. A robot can work continuously without breaks, which means that a task that would take a human crew several days can be completed in a shorter time. This reduces the time that a ship must spend in dry dock, which reduces the cost of downtime. A robot can also apply coatings more consistently, which reduces waste and improves the life of the coating. A longer-lasting coating means that the ship can go longer between maintenance intervals, which further reduces cost. | The safety benefits include reduced exposure to hazardous materials, reduced risk of falls, and reduced physical strain. Hull preparation and coating involve exposure to dust, fumes, solvents, and biocides. These materials can cause respiratory problems, skin irritation, and other health effects. By using a robot, workers can be kept away from the hazard. Falls from scaffolding or ropes are a leading cause of injury and death in shipyards. By using a robot, workers do not need to work at height. The physical strain of holding a heavy tool for hours is also eliminated. | In addition to these direct benefits, there are indirect benefits. For example, the use of robots can improve the reputation of a shipyard, making it more attractive to customers who care about safety and environmental performance. It can also help shipyards attract workers, since fewer workers are willing to perform dangerous and physically demanding jobs. Finally, the data collected by robots can be used to improve maintenance planning and to optimize the performance of the ship. |
| 56.12 Case Study: A Robotic Hull Cleaning System in a European Shipyard | To illustrate how these benefits are realized in practice, consider a case study of a robotic hull cleaning system in a European shipyard. The shipyard operates a dry dock that can accommodate ships up to 300 meters in length. The yard performs maintenance on a variety of vessels, including container ships, bulk carriers, and ferries. The yard has a long history of using manual methods for hull cleaning and painting, but it has faced increasing pressure to improve safety and reduce costs. | The yard decided to invest in a wall-climbing robot for hull cleaning. The robot is a crawler-type vehicle with magnetic wheels and a vacuum-assisted adhesion system. It weighs about 100 kilograms and can carry a payload of about 50 kilograms. It is equipped with a high-pressure water jet for cleaning and a vacuum recovery system for collecting the water and debris. The robot is controlled by an operator on the dock, who uses a joystick and a video feed. The robot can operate on vertical and overhead surfaces, and it can move at a speed of up to 10 meters per minute. | The yard used the robot to clean the hull of a container ship that had been in service for five years. The hull was covered with a layer of marine growth, including barnacles and algae, and there were patches of rust where the coating had failed. The yard's goal was to remove the marine growth and the rust and to prepare the surface for a new coating. | The robot was deployed on the hull after the ship was dry-docked. The operator guided the robot along the hull in a series of parallel passes. The high-pressure water jet removed the marine growth and the loose rust. The vacuum recovery system collected the water and debris, which was then filtered and disposed of. The robot was able to clean about 500 square meters per hour, which was significantly faster than the manual method, which achieved about 100 square meters per hour. | After cleaning, the yard inspected the hull and found that the surface was clean and ready for coating. The yard applied a new anti-corrosion coating using a combination of manual and robotic methods. The robot was used to apply the primer and the intermediate coat, while human workers applied the topcoat and the anti-fouling coating. The yard found that the robotic application was more consistent and used less paint than the manual method. | The yard reported several benefits from the robotic system. The cleaning time was reduced by about 50 percent. The amount of water and debris generated was reduced because of the vacuum recovery system. The safety of the workers was improved because they did not need to work at height or to handle the high-pressure water jet. The quality of the cleaning was improved because the robot maintained a constant distance and speed. The yard estimated that the robot would pay for itself within two years through reduced labor costs and improved quality. | This case study shows that wall-climbing robots can be successfully deployed in a real shipyard environment. It also shows that the benefits are not automatic; they depend on careful planning, training, and integration with existing processes. The yard had to train its operators to use the robot, and it had to adjust its workflow to accommodate the robot's capabilities and limitations. The yard also had to work with the robot's manufacturer to ensure that the robot was compatible with the yard's existing equipment and procedures. |
| 56.13 Case Study: A Robotic Painting System in an Asian Shipyard | A second case study illustrates the use of wall-climbing robots for painting. The shipyard is located in Asia and builds large commercial vessels, including oil tankers and bulk carriers. The yard has a large painting facility, but it has struggled to find enough workers to perform the painting tasks. The work is physically demanding and exposes workers to solvents and other chemicals. The yard decided to invest in a robotic painting system to address these problems. | The system consists of a wall-climbing robot with magnetic wheels and a spray gun. The robot is connected to a pump unit that supplies paint and compressed air. The robot is controlled by a computer that plans the painting path and adjusts the flow rate of the paint. The robot is equipped with sensors that measure the thickness of the coating and the distance to the surface. The data is used to ensure that the coating is applied uniformly and at the correct thickness. | The yard used the robot to paint the hull of an oil tanker. The hull was about 250 meters long and 40 meters high. The yard divided the hull into sections and painted each section in turn. The robot was able to paint about 200 square meters per hour, which was comparable to the speed of a human painter. However, the robot was able to work continuously for 12 hours without a break, while human painters required frequent breaks. The robot also used less paint because the spray pattern was more consistent and there was less overspray. | The yard reported that the robotic system improved the quality of the coating and reduced the amount of rework. The yard also reported that the system reduced the exposure of workers to hazardous chemicals, which improved worker safety and morale. The yard plans to expand the use of the system to other ships and to other parts of the painting process. |
| 56.14 Future Directions | The field of wall-climbing robots for shipbuilding is still evolving. Several trends are likely to shape its future. | The first trend is increased autonomy. Current systems are often teleoperated, which means that a human operator controls the robot remotely. Future systems may be more autonomous, able to plan their own paths, avoid obstacles, and adapt to changing conditions. This would reduce the need for skilled operators and would allow the robot to work in environments where communication is limited. | The second trend is improved adhesion and locomotion. Researchers are working on new adhesion methods, such as gecko-inspired dry adhesives, which could work on a wider range of surfaces. They are also working on new locomotion methods, such as snake-like robots that can move through confined spaces and around obstacles. These advances could allow robots to access areas of the hull that are currently difficult or impossible to reach. | The third trend is integration with digital systems. Shipyards are increasingly using digital tools for design, construction, and maintenance. Wall-climbing robots can be integrated with these tools, so that the data they collect is used to update the digital model of the ship. This would allow ship owners and operators to track the condition of the hull over time and to plan maintenance more effectively. | The fourth trend is collaboration between humans and robots. Rather than replacing human workers entirely, robots can work alongside them, performing the dangerous or repetitive tasks while humans perform the tasks that require judgment and skill. This approach, sometimes called cobotics, could be more practical and more acceptable than full automation. | The fifth trend is standardization and regulation. As wall-climbing robots become more common in shipyards, there will be a need for standards that define their safety, performance, and interoperability. Regulatory bodies may develop rules for the use of robots in shipbuilding, similar to the rules that exist for other types of industrial equipment. This would help to ensure that robots are used safely and effectively. |
| 56.15 Detailed Summary | This chapter has examined the use of wall-climbing robots in shipbuilding, with a focus on hull rust removal and painting. The following is a detailed summary of the main points. | Ship hulls are large, curved, and exposed to harsh marine environments. They require regular cleaning, rust removal, and coating to maintain their structural integrity and to reduce fuel consumption. Traditional methods for these tasks, such as scaffolding and rope access, are dangerous, expensive, and time-consuming. Wall-climbing robots offer an alternative that can improve safety, reduce cost, and improve quality. | Wall-climbing robots for ship hull work must solve three basic problems: adhesion, locomotion, and tooling. Adhesion methods include magnetic, vacuum, and thrust adhesion. Magnetic adhesion is common because most ship hulls are made of steel. Locomotion methods include wheels, tracks, and legs. Wheeled and tracked robots are the most common for ship hull work. Tooling includes blasting nozzles, water jets, wire brushes, and spray guns. The robot must be able to carry the tool, position it accurately, and manage the supply of grit, water, paint, or compressed air. | Wall-climbing robots can be used in several stages of the shipbuilding and ship repair workflow. In new construction, they can prepare and coat large flat areas of the hull. In repair and maintenance, they can clean and recoat the hull while the ship is in dry dock or afloat. They can also be used for inspection, such as measuring coating thickness or detecting cracks and corrosion. | Rust removal is one of the most important tasks. A wall-climbing robot for rust removal typically carries a blasting nozzle or a water jetting head. The robot moves across the hull surface in a planned pattern, removing rust and old coating as it goes. The abrasive grit or water is supplied through a hose from a support unit. The robot may have a shroud or enclosure around the tool to contain the dust and debris, which is then collected by a vacuum system. Robotic rust removal offers consistency, reduced worker exposure to hazards, and improved quality. | Painting and coating are also important. A wall-climbing robot for painting typically carries a spray gun or a roller. The robot moves across the hull in a programmed pattern, applying the coating in overlapping passes. The paint is supplied through a hose from a pump unit. The robot may have sensors to measure the thickness of the coating and to adjust the flow rate. Robotic painting reduces worker exposure to hazardous chemicals, improves consistency, and reduces waste. | Inspection and maintenance are additional applications. A robot can carry cameras, ultrasonic sensors, or eddy current probes to inspect the hull for cracks, corrosion, and coating defects. It can also measure the thickness of the steel and the coating. This data can be stored and compared over time to track the condition of the hull. Underwater inspection is a promising application, although it introduces additional challenges such as visibility, buoyancy, and corrosion of the robot itself. | Several examples from the shipbuilding industry illustrate the use of these robots. In South Korea, major shipbuilders have developed crawler-type robots with magnetic wheels for blasting and painting. In Europe, shipyards and research institutions have collaborated on robotic systems for hull cleaning and inspection. In the United States, the Navy has invested in robotic systems for ship maintenance. In Japan, shipyards have developed robots for applying anti-fouling coatings. In China, shipyards and universities have collaborated on robotic systems for hull cleaning and painting. In the offshore industry, similar robots are used for inspecting and maintaining platforms and wind turbines. | Compared with other industries, shipbuilding has some unique characteristics. The hull is a large, curved, ferrous surface, which makes magnetic adhesion a natural choice. The scale of the work is enormous, which provides a strong economic incentive for automation. The regulatory environment is strict, which requires robots to meet high standards of safety and performance. These characteristics have shaped the development of wall-climbing robots for shipbuilding. | Several technical challenges remain. Adhesion on curved and irregular surfaces is difficult. Navigation and positioning on a large, featureless surface is challenging. Tooling and process control require precise sensors and feedback control. Power and communication require careful design. Safety requires redundant systems and fall protection. Cost is a barrier for some shipyards. Researchers and engineers are working on solutions to these challenges, including new adhesion methods, improved sensors, and modular designs. | The economic and safety benefits of wall-climbing robots are significant. They include reduced labor costs, reduced downtime, improved quality, reduced exposure to hazardous materials, reduced risk of falls, and reduced physical strain. These benefits have been demonstrated in case studies in European and Asian shipyards. |
| The future of wall-climbing robots in shipbuilding is likely to be shaped by increased autonomy, improved adhesion and locomotion, integration with digital systems, collaboration between humans and robots, and standardization and regulation. These trends will determine how quickly and how widely the technology is adopted. | In conclusion, wall-climbing robots are a powerful tool for shipbuilding and ship repair. They can perform hull rust removal and painting in shipyards, eliminating scaffolding and rope access hazards. They can improve safety, reduce cost, and improve quality. As the technology continues to develop, it is likely to play an increasingly important role in the shipbuilding industry and in other industries that require work on large vertical surfaces. |
|
